Using “LUMIX Lab”

This explains the functions for operating the camera from “LUMIX Lab”.

LUT Library Operations

Operate “LUMIX Lab” to update the [LUT Library] in the camera.

Getting started:

Connect the camera to a smartphone by Bluetooth. ( character_reference Connecting to a Smartphone (Bluetooth Connection))

On the smartphone, start up “LUMIX Lab”.

Select [LUT Transfer] in the [Camera] screen.

Connect to the camera with Wi-Fi. Select [Join] to start the connection.

image_lab-use01

(A) [LUT Transfer]

Select the LUT file in the [LUT Library] screen to edit.

You can transfer, rename, delete or reorder your LUT files.

A list of LUT files saved to “LUMIX Lab” is shown in [Device].

A list of LUT files saved to the camera is shown in [Camera].

image_lab-use02

Select from [Device] the LUT file to transfer.

Select [Transfer to Camera] and update the [LUT Library] on the camera.

icon_info_s

When the following function is being used, [Bluetooth] is not available:

– [Frame.io Connection]

Import images

Operate “LUMIX Lab” to transfer images from the camera to your smartphone.

Getting started:

Connect the camera to a smartphone. ( character_reference Connecting to a Smartphone (Bluetooth Connection))

On the smartphone, start up “LUMIX Lab”.

Select [Transfer Photo / Video] in the [Camera] screen.

Connect to the camera with Wi-Fi. Select [Join] to start the connection.

Select the image to transfer.

Touch the checkbox to select.

image_lumixlab-play01

Transfer the image.

Select [ icon_transferlab ].

image_lumixlab-play02

icon_info_s

It is not possible to transfer images with file sizes exceeding 4 GB.

Images recorded using the following function cannot be transferred:

– [MOV], [Apple ProRes] videos

When the following function is being used, [Bluetooth] is not available:

– [Frame.io Connection]

The transfer speed slows when the camera temperature rises.

[Auto Transfer]

You can automatically transfer images from the camera to your smartphone as they are taken.

Getting started:

Connect the camera to a smartphone by Bluetooth. ( character_reference Connecting to a Smartphone (Bluetooth Connection))

Enable [Auto Transfer] on the camera.

button_menu-set [] [ icon_setup-inout ] [Bluetooth] [Auto Transfer] [ON]

The function can also be enabled in “LUMIX Lab”.

Connect to the smartphone with Wi-Fi.

Check the send settings on the camera and then press .

To change the send setting, press [DISP.]. ( character_reference Image Send Settings)

Automatic image transfer is possible when [ icon_wi-fi-sending1 ] is displayed on the camera recording screen.

gui_wi-fi-auto-image-transfer-02_eng

Record with the camera.

[ icon_wi-fi-sending2 ] is displayed in the recording screen of the camera while a file is being sent.

character_diamond To Stop the Automatic Transfer of Images

button_menu-set [] [ icon_setup-inout ] [Bluetooth] [Auto Transfer] Select [OFF]

A confirmation screen is displayed, asking you to terminate the Wi-Fi connection.

icon_hints_s

If the [Bluetooth Function] and [Auto Transfer] settings of the camera are [ON], the camera automatically connects to the smartphone via Wi-Fi and Bluetooth when you turn on the camera.

Start up the “LUMIX Lab” on the smartphone to connect to the camera. Note that if “LUMIX Sync” is running on the smartphone, automatic image transfer may not work properly.

icon_info_s

When [Auto Transfer] is set to [ON], [Wi-Fi Function] cannot be used.

Automatic image transfer is interrupted while recording or playing back videos. The transfer starts at the start of the file where it was interrupted when the transmission restarts.

If the camera is turned off during image transfer, and the file sending is interrupted, then turn on the camera to restart the sending.

– If the storage status of unsent files changes, then sending of files may no longer be possible.

– If there are many unsent files, then sending of all files may not be possible.

If automatic image transfer is performed in places where the ambient temperature is high, communications may be interrupted.

The camera automatically reconnects when its temperature goes down and automatic image transfer restarts.

If automatic image transfer does not restart, turn the camera off then on again to reconnect.

Images recorded with the following function cannot be transferred automatically:

– Video recording

When the following function is being used, [Bluetooth] is not available:

– [Frame.io Connection]

[Location Logging]

The smartphone sends its location information to the camera via Bluetooth, and the camera performs recording while writing the acquired location information.

Getting started:

Enable the GPS function on the smartphone.

Connect the camera to a smartphone by Bluetooth. ( character_reference Connecting to a Smartphone (Bluetooth Connection))

Enable [Location Logging] on the camera.

button_menu-set [] [ icon_setup-inout ] [Bluetooth] [Location Logging] [ON]

The function can also be enabled in “LUMIX Lab”.

The camera will enter a mode where location information can be recorded and [ icon_gps ] is displayed in the recording screen of the camera.

Record images with the camera.

Location information will be written to the recorded images.

icon_info_s

When [ icon_gps ] on the recording screen appears translucent, location information cannot be acquired, therefore data cannot be written.

Smartphone GPS positioning may not be possible if the smartphone is within a building, a bag, or similar. Move the smartphone to a position affording a wide view of the sky to improve positioning performance.

In addition, refer to the operating instructions of your smartphone.

Images with location information are indicated with [ icon_gps ].

Be sure to pay special attention to the privacy, the likeness rights, etc. of the subject when you use this function. Use at your own risk.

The smartphone drains its battery faster while acquiring location information.

When the following function is being used, [Bluetooth] is not available:

– [Frame.io Connection]
