Panasonic | DC-S9 | Operating Instructions

Wi-Fi / Bluetooth
Using “LUMIX Sync”

Using “LUMIX Sync”

[Remote shooting]

[Shutter Remote Control]

[Camera settings copy]

This explains the functions for operating the camera from “LUMIX Sync”.

Functions described in this document with the ( icon_need-bluetooth ) symbol require a smartphone that supports Bluetooth Low Energy.

character_diamond Home Screen

When you start up “LUMIX Sync”, the home screen is displayed.

image_lumixsync-home

(A) : App settings ( character_reference Connecting to a Paired Smartphone, Connecting to a Smartphone ([Wi-Fi connection]), [Remote Wakeup])

This allows connection settings, camera power operations, and displays Help.

(B) icon_wi-fi-playback : [Import images] ( character_reference [Import images])

(D) icon_app-remo-con : [Shutter Remote Control] ( character_reference [Shutter Remote Control])

(E) icon_image-app-tool : [Others] ([Camera settings copy]) ( character_reference [Camera settings copy])

[Remote shooting]

You can use the smartphone to record from a remote location while viewing the live view images from the camera.

Getting started:

Connect the camera to a smartphone. ( character_reference Connecting to a Smartphone (Bluetooth Connection), Connecting to a Smartphone ([Wi-Fi connection]))

On the smartphone, start up “LUMIX Sync”.

Select [] ([Remote shooting]) in the home screen.

(iOS devices) When a message to confirm the change of destination is displayed, select [Join].

Start recording.

The recorded image is saved on the camera.

image_lumix-sync-remote2

(F) Takes a picture

(G) Starts/ends the video recording

icon_hints_s

When used in combination with [Auto Transfer], it is possible to automatically transfer the remotely recorded images to a smartphone. ( character_reference [Auto Transfer])

icon_info_s

Certain features, including some settings, may not be available.

character_diamond Operation Method During Remote Recording

Set either the camera or the smartphone as the priority control device to be used during remote recording.

button_menu-set [] [ icon_setup-inout ] [Wi-Fi] [Wi-Fi Setup] Select [Priority of Remote Device]

icon_wi-fi-camera [Camera]

Operation is possible on both the camera and the smartphone.

The camera’s dial settings, etc. cannot be changed with the smartphone.

icon_wi-fi-smartphone [Smartphone]

Operation is possible only on the smartphone.

The camera’s dial settings, etc. can be changed with the smartphone.

To end remote recording, press any of the buttons on the camera to turn on the screen, and select [End].

The default setting is [Camera].

icon_info_s

The setting of this function cannot be changed while the connection is active.

[Shutter Remote Control]

icon_need-bluetooth

You can use the smartphone as a remote control for the shutter.

Getting started:

Connect the camera to a smartphone by Bluetooth. ( character_reference Connecting to a Smartphone (Bluetooth Connection))

On the smartphone, start up “LUMIX Sync”.

Select [] ([Shutter Remote Control]) in the home screen.

Start recording.

image_lumix-sync-blue-remo2

icon_image-app-rec-v-g

Starts/ends the video recording

icon_image-app-shutter-g

Takes a picture

Bulb Recording

character_diamond Bulb Recording

The shutter can be kept open from the start to end of recording, which is useful for recording of starry skies or night scenery.

Getting started:

Set the camera to [M] mode. ( character_reference Manual Exposure Mode)

Set the camera shutter speed to [T] (Time). ( character_reference [T] (Time))

Touch [] to start recording (keep touching, without removing your finger).

Remove your finger from [] to end recording.

Slide [ icon_image-app-shutter-g ] in the direction of [LOCK] to record with the shutter button locked in a fully-pressed state.

(Slide [ icon_image-app-shutter-y ] back to its original position or press the camera shutter button to end recording)

During [B] (Bulb) recording, if the Bluetooth connection is broken, then carry out Bluetooth connection again, then end recording from the smartphone.

character_diamond Shortening the Return Time from [Sleep Mode]

You can shorten the time it takes for the camera to return from [Sleep Mode] when the [Shutter Remote Control] is used.

Getting started:

Connect the camera to a smartphone by Bluetooth. ( character_reference Connecting to a Smartphone (Bluetooth Connection))

Set [Remote Wakeup] in [LUMIX Sync Settings] to [ON]. ( character_reference [Remote Wakeup])

button_menu-set [] [ icon_setup-inout ] [Bluetooth] [LUMIX Sync Settings] Select [Returning from Sleep Mode]

icon_priority-remote-cotrol [Import / Remote Priority]

Shortens the time to return when using [Import images] or [Remote shooting].

icon_priority-shutter [Remote Shutter Priority]

Shortens the time to return when using [Shutter Remote Control].

icon_info_s

To use the [Shutter Remote Control] to cancel [Sleep Mode] on the camera, set [Bluetooth] in the [Setup] ([IN/OUT]) menu as follows, then connect via Bluetooth:

– [Remote Wakeup] ([LUMIX Sync Settings]): [ON] ( character_reference [Remote Wakeup])

– [Auto Transfer]: [OFF] ( character_reference [Auto Transfer])

The camera cannot be turned on by using [Shutter Remote Control].

[Import images]

Transfer an image stored on the card to the smartphone connected via Wi-Fi.

Getting started:

Connect the camera to a smartphone. ( character_reference Connecting to a Smartphone (Bluetooth Connection), Connecting to a Smartphone ([Wi-Fi connection]))

On the smartphone, start up “LUMIX Sync”.

Select [] ([Import images]) in the home screen.

(iOS devices) When a message to confirm the change of destination is displayed, select [Join].

Select the image to transfer.

image_lumixsync-play02

Transfer the image.

Select [ icon_transfer ].

If the image is a video, you can play it back by touching [ icon_play-picture-smartphone_s ] at the center of the screen.

image_lumix-sync-play03

icon_info_s

When a video is played back, this has a small data size and is transmitted using “LUMIX Sync”, therefore its image quality will differ from that of the actual video recording.

Depending on the smartphone and on the usage conditions, the image quality may deteriorate or the sound may skip during video or picture playback.

It is not possible to transfer images with file sizes exceeding 4 GB.

Images recorded using the following function cannot be transferred:

– [MOV] videos

The transfer speed slows when the camera temperature rises.

[Auto Transfer]

icon_need-bluetooth

You can automatically transfer recorded pictures to a smartphone as they are taken.

Getting started:

Connect the camera to a smartphone by Bluetooth. ( character_reference Connecting to a Smartphone (Bluetooth Connection))

Enable [Auto Transfer] on the camera.

button_menu-set [] [ icon_setup-inout ] [Bluetooth] [Auto Transfer] [ON]

If a confirmation screen is displayed on the camera asking you to terminate the Wi-Fi connection, select [Yes] to terminate it.

On the smartphone, select [Yes] (for Android devices) or [Join] (for iOS devices).

The camera automatically makes a Wi-Fi connection.

Check the send settings on the camera and then press .

To change the send setting, press [DISP.]. ( character_reference Image Send Settings)

Automatic image transfer is possible when [ icon_wi-fi-sending1 ] is displayed on the camera recording screen.

gui_wi-fi-auto-image-transfer-02_eng

Record with the camera.

[ icon_wi-fi-sending2 ] is displayed in the recording screen of the camera while a file is being sent.

character_diamond To Stop the Automatic Transfer of Images

button_menu-set [] [ icon_setup-inout ] [Bluetooth] [Auto Transfer] Select [OFF]

A confirmation screen is displayed, asking you to terminate the Wi-Fi connection.

icon_hints_s

If the [Bluetooth Function] and [Auto Transfer] settings of the camera are [ON], the camera automatically connects to the smartphone via Wi-Fi and Bluetooth when you turn on the camera.

Start up the “LUMIX Sync” on the smartphone to connect to the camera. Note that if “LUMIX Lab” is running on the smartphone, automatic image transfer may not work properly.

icon_info_s

Images are not transferred while the recording screen of the camera is displayed on the smartphone in [Remote shooting].

When [Auto Transfer] is set to [ON], [Wi-Fi Function] cannot be used.

Automatic image transfer is interrupted while recording or playing back videos. The transfer starts at the start of the file where it was interrupted when the transmission restarts.

If the camera is turned off during image transfer, and the file sending is interrupted, then turn on the camera to restart the sending.

– If the storage status of unsent files changes, then sending of files may no longer be possible.

– If there are many unsent files, then sending of all files may not be possible.

Images recorded with the following function cannot be transferred automatically:

– Video recording

[Location Logging]

icon_need-bluetooth

The smartphone sends its location information to the camera via Bluetooth, and the camera performs recording while writing the acquired location information.

Getting started:

Enable the GPS function on the smartphone.

Connect the camera to a smartphone by Bluetooth. ( character_reference Connecting to a Smartphone (Bluetooth Connection))

Enable [Location Logging] on the camera.

button_menu-set [] [ icon_setup-inout ] [Bluetooth] [Location Logging] [ON]

The camera will enter a mode where location information can be recorded and [ icon_gps ] is displayed in the recording screen of the camera.

Record images with the camera.

Location information will be written to the recorded images.

icon_info_s

When [ icon_gps ] on the recording screen appears translucent, location information cannot be acquired, therefore data cannot be written.

Smartphone GPS positioning may not be possible if the smartphone is within a building, a bag, or similar. Move the smartphone to a position affording a wide view of the sky to improve positioning performance.

In addition, refer to the operating instructions of your smartphone.

Images with location information are indicated with [ icon_gps ].

Be sure to pay special attention to the privacy, the likeness rights, etc. of the subject when you use this function. Use at your own risk.

The smartphone drains its battery faster while acquiring location information.

[Remote Wakeup]

icon_need-bluetooth

Even when the camera is turned off, the smartphone can be used to start the camera and record images, or check the recorded images.

Getting started:

Connect to a smartphone using Bluetooth. (Connecting to a Smartphone (Bluetooth Connection))

Enable [Remote Wakeup] on the camera.

button_menu-set [] [ icon_setup-inout ] [Bluetooth] [LUMIX Sync Settings] [Remote Wakeup] [ON]

Set the camera on/off switch to [OFF].

On the smartphone, start up “LUMIX Sync”.

character_diamond Turning On the Camera

Select [Remote shooting] in the “LUMIX Sync” home screen.

(iOS devices) When a message to confirm the change of destination is displayed, select [Join].

The camera turns on, and automatically connects using Wi-Fi.

character_diamond Turning Off the Camera

Select [] in the “LUMIX Sync” home screen.

Select [Turn off the camera].

Select [Power OFF].

icon_info_s

When [Auto Transfer] is set to [ON], images recorded while remote operation is running are automatically transferred to a smartphone.

If [Power OFF] is selected while there are still unsent images, sending is resumed when the camera is next turned on.

When [Remote Wakeup] has been set, the Bluetooth function continues to work even if the camera on/off switch is set to [OFF], so the battery will drain.

[Auto Clock Set]

icon_need-bluetooth

Synchronize the clock and the time zone setting of the camera with those of a smartphone.

Getting started:

Connect the camera to a smartphone by Bluetooth. ( character_reference Connecting to a Smartphone (Bluetooth Connection))

Enable [Auto Clock Set] on the camera.

button_menu-set [] [ icon_setup-inout ] [Bluetooth] [LUMIX Sync Settings] [Auto Clock Set] [ON]

[Camera settings copy]

icon_need-bluetooth

This saves the camera’s settings information to the smartphone.

Saved settings information can be loaded to the camera, letting you set the same settings on multiple cameras.

Getting started:

Connect the camera to a smartphone by Bluetooth. ( character_reference Connecting to a Smartphone (Bluetooth Connection))

Select [] ([Others]) [] ([Camera settings copy]) in the “LUMIX Sync” home screen.

Save or load settings information.

Read the [Help] in the “LUMIX Sync” menu for further details on how to operate the “LUMIX Sync”.

icon_info_s

Only settings information from the same model can be loaded.

When transferring settings information, a Wi-Fi connection is automatically created.

(iOS devices) When a message to confirm the change of destination is displayed, select [Join].

You can save or load the settings information of items that are the same as those in [Save/Restore Camera Setting] under the [Setup] ([Setting]) menu. ( character_reference List of Default Settings/Custom Saving/Settings Available for Copying)
