Setting the shutter speed

image_gui_shutter

(A) Shutter speed

bullet02[A.SHTR] is displayed when the auto shutter mode is on.

(B) SHUTTER


  1. Switch to manual mode with the <AUTO/MANU> switch. (character_referenceAbout auto mode/manual mode)

  1. Press the <SHUTTER> button to switch to manual shutter mode.

The shutter speed display is highlighted in orange.

  1. Turn the multidial to select the shutter speed.

  1. Press the multidial.

The setting changes to the value displayed and exits.

Press the <EXIT> button to exit without changing the setting.


character_diamondAdjusting the shutter speed

Shutter speed changes depending on the frame rate of the [REC FORMAT] in the [SYSTEM] menu. (character_referenceSelecting the resolution, codec, and frame rate for recording video)

Frame rates

Shutter speed

59.94p/59.94i

1/8icon_arrow-s1/15icon_arrow-s1/30icon_arrow-s1/60icon_arrow-s...1/8000

29.97p

1/8icon_arrow-s1/15icon_arrow-s1/30icon_arrow-s1/50icon_arrow-s...1/8000

50.00p/50.00i/25.00p

1/6icon_arrow-s1/12icon_arrow-s1/25icon_arrow-s1/50icon_arrow-s...1/8000

23.98p

1/6icon_arrow-s1/12icon_arrow-s1/24icon_arrow-s1/48icon_arrow-s...1/8000

bullet02The shutter speed is faster the closer the setting is to 1/8000.


bullet02Brightly shining objects and highly reflective objects may emit light bands into the surroundings.

bullet02The changing of the screen may not look smooth in normal playback.

bullet02When extremely bright subjects are recorded or when recording is performed inside under lights, there may be changes in the color hue and brightness of the screen, with horizontal bands appearing on the screen. Do the following if this occurs:

– Switch to auto shutter mode.

– Adjust the shutter speed to 1/50, 1/60, or 1/100.

bullet02When auto iris mode or auto gain mode is enabled, the brightness of the screen may not change even when you adjust the shutter speed. (character_referenceIris, Gain)

bullet02When the shutter speed has been set to slow shutter, it may not be possible for the camera to keep up with changes in the images. If this occurs, set the iris, focus, and white balance manually.
