AE level (exposure compensation)

image_gui_ae-level

(A) Exposure compensation value

(B) AE LEVEL


character_diamondAdjusting with the rear ring

  1. Select the [SCENE FILE] menu character_arrow [AE LEVEL] character_arrow [ON].

  1. Select the [CAMERA] menu character_arrow [SW MODE] character_arrow [REAR RING] character_arrow [IRIS/AE LEVEL].

  1. When the <AUTO/MANU> switch is set to manual mode, use one of the following operations to switch one of iris, gain, or shutter speed to auto.

bullet02Press the <IRIS> button to switch to auto iris mode.

bullet02Press the <GAIN> button to switch to auto gain mode.

bullet02Press the <SHUTTER> button to switch to auto shutter mode.

  1. Rotate the rear ring.

At this time, the settings in [SCENE FILE] menu character_arrow [AE LEVEL EFFECT] are not reflected.


bullet02When manual iris mode is enabled, the iris is adjusted when the rear ring is turned.


character_diamondSetting with the multi manual function

  1. Select the [SCENE FILE] menu character_arrow [AE LEVEL] character_arrow [ON].

  1. Select the [CAMERA] menu character_arrow [SW MODE] character_arrow [REAR RING] character_arrow [ZOOM] or [IRIS].

  1. Switch one of iris, gain, or shutter speed to auto.

  1. Turn the multidial to display [imageicon_operation_icon AE LEVEL].

  1. Press the multidial.

The AE level display is highlighted in orange.

  1. Turn the multidial to adjust, then press the multidial.

The setting changes to the value displayed and exits.

Press the <EXIT> button to exit without changing the setting.


character_diamondApplications for the USER button

You can also either press the USER button assigned to [AE LEVEL] or touch the USER button icon to switch enable/disable of [AE LEVEL].

bullet02[AE LEVEL] is set in the <USER6> button at the time of purchase.

bullet02For USER button settings (character_referenceAssigning functions to the USER buttons)


bullet02AE level adjustments are not possible when IR recording is enabled.
