Recording While Controlling Overexposure (Knee)

When [Photo Style] is set to [Like709], you can adjust the knee so that recording can be performed with minimal overexposure.

1Set [Photo Style] to [Like709].

[MENU/SET] arrow_menu [menuicon_video] arrow_menu [menuicon_imagequality] arrow_menu [Photo Style] arrow_menu [Like709]

sc_ill_photostyle_709l_adjust



2Press [Q.MENU].

img_ch3_02



3Select a knee setting.

Press sankaku_l_r to select a setting item.

[AUTO]

Adjusts the compression levels of high-luminance areas automatically.

[MANUAL]

You can set the luminance where compression starts (knee master point) and

the intensity of compression (knee master slope).



number_k_01Press sankaku_u_d to select an item and then press sankaku_l_r to adjust.

[POINT]: Master knee point

[SLOPE]: Master knee slope

Values within the following ranges can be set:

–Master knee point: 80.0 to 107.0

–Master knee slope: 0 to 99

[Off]

―



4Confirm your selection.

Press [MENU/SET].
